General Features
| Application Area | Conductive Liquids |
| Minimum Conductivity | > 5 microsiemens |
| Temperature | Hard Rubber -20 ... +60 °C / PTFE 125 °C Optional: 180 °C |
| Pressure | PN6 ... PN63 Optional: PN100 |
| Connection Size | DN10 ... DN2000 |
| Connection Standard | DIN, JIS, ANSI |
| Measuring Range | 0.3 ... 10 m/s |
| Wetted Parts | Electrodes AISI316L, Hastelloy C, Tantalum, Titanium Lining Material Hard Rubber, PTFE |
| Connection Parts | Stainless Steel, Carbon Steel |
| Housing | Epoxy Coated Aluminum |
| Analog Output Signal | 4...20 mA |
| Digital Output Signal | Pulse/Frequency |
| Communication Protocol | HART, RS-485 Modbus, Profibus PA, Foundation Fieldbus |
| Power Supply | 24 VDC, 230 VAC, Internal Battery Powered |
| Protection Class | IP67 / IP68 |
| Certification | Ex d, Ex ia |
| Accuracy | ±0.5% Std. (±0.1% .. ±0.2% Optional) |
| Display Options | Compact, Remote (Separated) |
| Display Parameters | Instantaneous and Total Flow Rate |
| Alarm Parameters | Low/High Flow Rate, Empty Pipe Alarm |
| Quality Certificates | ISO 9001 / CE |
